ARM Cortex-M Boot and Remap Signal Functionality in System Design Kit

The relationship between BOOT and REMAP signals in ARM Cortex-M System Design Kits (CMSDK) is a critical aspect of system initialization and memory mapping. These signals are often misunderstood due to their nuanced behavior and the lack of explicit documentation in some design kits. This guide will provide a detailed breakdown of the functionality, possible causes of confusion, and troubleshooting steps to address issues related to these signals.

Boot and Remap Signal Behavior in CMSDK

In the ARM Cortex-M System Design Kit, the BOOT and REMAP signals play a pivotal role in determining the memory space from which the system boots and how memory regions are mapped during initialization. The BOOT signal, when present, allows the system designer to select the memory region from which the processor boots. This is typically achieved by remapping a small memory region starting at address 0x00000000 to a different memory space. The REMAP signal, on the other hand, controls whether the memory region at 0x00000000 is mapped to the boot ROM or the application ROM.

In the CMSDK, the default implementation includes only one application ROM area. However, there is an option to include a boot loader ROM. The boot loader code, if present, executes the same application image, making the BOOT configuration pin unnecessary in this context. The REMAP signal is used to control the mapping of the memory region at 0x00000000. When REMAP is set to 1, the memory region at 0x00000000 is mapped to the boot ROM. After the boot ROM program starts, the REMAP signal can be switched to 0 by software, which then maps the memory region at 0x00000000 to the user ROM or flash.

The confusion often arises when the REMAP signal is observed to be stuck at 1 and does not change during simulation. This behavior is normal in the default configuration of the CMSDK, where the boot ROM is not present, and the REMAP signal is ignored. However, if the boot ROM is enabled, the REMAP signal should transition from 1 to 0 after the boot ROM program starts.

Memory Mapping and Boot Configuration in CMSDK

The memory mapping and boot configuration in the CMSDK are controlled by several key signals and parameters. The remap_ctrl signal is used to control the mapping of the memory region at 0x00000000. When remap_ctrl is set to 1, the memory region at 0x00000000 is mapped to the boot ROM. After the boot ROM program starts, remap_ctrl can be switched to 0, which maps the memory region at 0x00000000 to the user ROM or flash.

The boot_hsel and flash_hsel signals are used to select between the boot ROM and the user ROM or flash. The boot_hsel signal is generated based on the address and the remap_ctrl signal. If the address is in the range 0x00000000 to 0x0000FFFF and remap_ctrl is 1, boot_hsel is set to 1, selecting the boot ROM. Otherwise, boot_hsel is set to 0, selecting the user ROM or flash.

The ARM_CMSDK_BOOT_MEM_TYPE parameter in the cmsdk_mcu_defs.v file determines whether the boot ROM is present. If ARM_CMSDK_BOOT_MEM_TYPE is set to AHB_ROM_NONE, the boot ROM is not present, and the remap_ctrl signal is ignored. In this case, BOOT_LOADER_PRESENT is set to 0, and the system boots directly from the user ROM or flash.

Troubleshooting Boot and Remap Signal Issues in CMSDK

When troubleshooting issues related to the BOOT and REMAP signals in the CMSDK, it is essential to understand the configuration of the system and the behavior of the signals. The following steps can be taken to diagnose and resolve issues:

  1. Verify the Configuration of ARM_CMSDK_BOOT_MEM_TYPE: Ensure that the ARM_CMSDK_BOOT_MEM_TYPE parameter in the cmsdk_mcu_defs.v file is set correctly. If the boot ROM is not required, set ARM_CMSDK_BOOT_MEM_TYPE to AHB_ROM_NONE. This will disable the boot ROM and ignore the remap_ctrl signal.

  2. Check the Generation of boot_hsel and flash_hsel Signals: Examine the logic that generates the boot_hsel and flash_hsel signals. Ensure that these signals are generated correctly based on the address and the remap_ctrl signal. If the boot ROM is not present, boot_hsel should always be 0.

  3. Simulate the Boot Process: Run a simulation of the boot process to observe the behavior of the remap_ctrl signal. If the boot ROM is enabled, the remap_ctrl signal should transition from 1 to 0 after the boot ROM program starts. If the boot ROM is not enabled, the remap_ctrl signal should remain at 0.

  4. Review the Boot Loader Code: If a boot loader is present, review the boot loader code to ensure that it correctly switches the remap_ctrl signal from 1 to 0 after the boot ROM program starts. The boot loader should also correctly branch to the application code space.

  5. Examine the Address Decoder Logic: Ensure that the address decoder logic correctly maps the memory region at 0x00000000 to the boot ROM or the user ROM/flash based on the remap_ctrl signal. The address decoder should also handle the transition from the boot ROM to the user ROM/flash correctly.

  6. Check for Stuck Signals: If the remap_ctrl signal is observed to be stuck at 1, verify that the boot ROM is not enabled and that the ARM_CMSDK_BOOT_MEM_TYPE parameter is set to AHB_ROM_NONE. If the boot ROM is enabled, ensure that the boot loader code correctly switches the remap_ctrl signal to 0.

  7. Review the System Design: If the system design includes multiple application ROMs, ensure that the boot configuration pin is correctly implemented at the system level. The boot configuration pin should capture the status at reset and control the behavior of the address decoder to select the appropriate application program space.

By following these steps, you can diagnose and resolve issues related to the BOOT and REMAP signals in the ARM Cortex-M System Design Kit. Understanding the behavior of these signals and their interaction with the memory mapping and boot configuration is essential for ensuring a reliable system implementation.
