ARM Cortex-M3/M4/M7 Lack Native TrustZone Support

The ARM Cortex-M3, Cortex-M4, and Cortex-M7 processors are based on the ARMv7-M architecture, which does not include native support for ARM TrustZone technology. TrustZone, a hardware-based security feature, was introduced in the ARMv8-M architecture, specifically for Cortex-M23 and Cortex-M33 processors. TrustZone provides a hardware-enforced separation between secure and non-secure states, allowing developers to create a Trusted Execution Environment (TEE) for sensitive operations such as cryptographic key management, secure boot, and secure firmware updates.

The absence of TrustZone in Cortex-M3/M4/M7 processors poses a challenge for developers who require a secure execution environment but are constrained to using these older architectures. While these processors are widely used in embedded systems due to their cost-effectiveness and performance, their lack of hardware-based security features necessitates alternative approaches to implement a software-level TrustZone-like environment.

Software-Based TrustZone Alternatives for ARMv7-M Processors

Given the hardware limitations of Cortex-M3/M4/M7 processors, developers must rely on software-based solutions to emulate a Trusted Execution Environment. These solutions typically involve partitioning the system into secure and non-secure domains using software mechanisms such as memory protection units (MPUs), privileged execution modes, and custom software layers. However, these approaches are inherently less secure than hardware-based TrustZone, as they rely on software enforcement, which can be bypassed by sophisticated attacks.

One common approach is to use the MPU available in Cortex-M3/M4/M7 processors to create memory regions with restricted access. By configuring the MPU to enforce access permissions, developers can isolate sensitive code and data from non-secure applications. However, the MPU has limitations, such as a finite number of configurable regions and the inability to dynamically switch contexts without reconfiguring the MPU, which can introduce latency and complexity.

Another approach is to leverage the processor’s privileged and unprivileged execution modes. By running sensitive code in privileged mode and non-secure code in unprivileged mode, developers can restrict access to critical system resources. However, this method relies on software discipline and does not provide the same level of isolation as hardware-based TrustZone.

Additionally, custom software layers, such as secure bootloaders and runtime security monitors, can be implemented to enforce security policies. These layers can perform integrity checks, manage secure and non-secure transitions, and monitor system behavior for anomalies. However, these solutions require careful design and validation to ensure they do not introduce vulnerabilities or performance bottlenecks.

Implementing a Software-Level TrustZone on Cortex-M3/M4/M7

To implement a software-level TrustZone on Cortex-M3/M4/M7 processors, developers must carefully design and integrate multiple software components to emulate the security features provided by hardware-based TrustZone. The following steps outline a comprehensive approach to achieving this:

Step 1: Define Secure and Non-Secure Memory Regions

The first step is to partition the system’s memory into secure and non-secure regions using the MPU. This involves defining memory regions for secure code, secure data, non-secure code, and non-secure data. The MPU should be configured to enforce strict access permissions, ensuring that non-secure code cannot access secure regions. For example, secure code and data can be placed in a protected region of flash memory, while non-secure code and data can reside in a separate region with restricted access.

Step 2: Implement Privileged and Unprivileged Execution Modes

Next, developers should leverage the processor’s privileged and unprivileged execution modes to enforce security boundaries. Sensitive operations, such as cryptographic functions and secure boot, should be executed in privileged mode, while non-secure applications should run in unprivileged mode. This ensures that non-secure code cannot directly access critical system resources or modify secure configurations.

Step 3: Develop a Secure Bootloader

A secure bootloader is essential for establishing a root of trust and ensuring the integrity of the system. The bootloader should verify the authenticity and integrity of the firmware before allowing it to execute. This can be achieved using cryptographic signatures and hash checks. Once the firmware is verified, the bootloader should transition the system to the appropriate execution mode and configure the MPU to enforce memory protection.

Step 4: Create a Runtime Security Monitor

A runtime security monitor is a software component that continuously monitors system behavior for anomalies and enforces security policies. The monitor should be designed to detect unauthorized access attempts, privilege escalation, and other security violations. It should also manage transitions between secure and non-secure states, ensuring that sensitive operations are isolated from non-secure code.

Step 5: Implement Secure and Non-Secure Communication Mechanisms

Secure and non-secure domains must communicate securely to exchange data and coordinate operations. Developers should implement secure communication mechanisms, such as message queues or shared memory regions with access controls, to facilitate this interaction. These mechanisms should be designed to prevent unauthorized access and ensure data integrity.

Step 6: Validate and Test the Software-Level TrustZone Implementation

Finally, the software-level TrustZone implementation must be rigorously validated and tested to ensure it meets security requirements. This includes testing for vulnerabilities, performance bottlenecks, and compliance with industry standards. Developers should also consider third-party security assessments to identify potential weaknesses and improve the overall robustness of the system.

Example Implementation

Below is an example of how to configure the MPU on a Cortex-M4 processor to create secure and non-secure memory regions:

// Define memory regions for secure and non-secure code and data
#define SECURE_FLASH_START   0x00000000
#define SECURE_FLASH_END     0x0000FFFF
#define NON_SECURE_FLASH_START 0x00010000
#define NON_SECURE_FLASH_END   0x0001FFFF
#define SECURE_RAM_START     0x20000000
#define SECURE_RAM_END       0x2000FFFF
#define NON_SECURE_RAM_START   0x20010000
#define NON_SECURE_RAM_END     0x2001FFFF

// Configure MPU regions
void configure_mpu() {
    // Disable MPU
    MPU->CTRL = 0;

    // Configure secure flash region
    MPU->RNR = 0;
    MPU->RBAR = SECURE_FLASH_START;
    MPU->RASR = (0x01 << 24) | (0x03 << 19) | (0x01 << 18) | (0x01 << 17) | (0x01 << 16) | (0x01 << 8) | 0x03;

    // Configure non-secure flash region
    MPU->RNR = 1;
    MPU->RBAR = NON_SECURE_FLASH_START;
    MPU->RASR = (0x01 << 24) | (0x03 << 19) | (0x01 << 18) | (0x01 << 17) | (0x01 << 16) | (0x01 << 8) | 0x03;

    // Configure secure RAM region
    MPU->RNR = 2;
    MPU->RBAR = SECURE_RAM_START;
    MPU->RASR = (0x01 << 24) | (0x03 << 19) | (0x01 << 18) | (0x01 << 17) | (0x01 << 16) | (0x01 << 8) | 0x03;

    // Configure non-secure RAM region
    MPU->RNR = 3;
    MPU->RBAR = NON_SECURE_RAM_START;
    MPU->RASR = (0x01 << 24) | (0x03 << 19) | (0x01 << 18) | (0x01 << 17) | (0x01 << 16) | (0x01 << 8) | 0x03;

    // Enable MPU
    MPU->CTRL = 1;
}

This example demonstrates how to configure the MPU to create secure and non-secure memory regions for flash and RAM. The MPU is configured to enforce access permissions, ensuring that non-secure code cannot access secure regions.

Conclusion

While ARM Cortex-M3/M4/M7 processors lack native TrustZone support, developers can implement a software-level TrustZone using a combination of memory protection, privileged execution modes, and custom software layers. This approach requires careful design and validation to ensure security and performance. By following the steps outlined above, developers can create a secure execution environment for sensitive operations, even on processors without hardware-based TrustZone. However, it is important to recognize the limitations of software-based solutions and consider upgrading to ARMv8-M processors with native TrustZone support for applications requiring higher levels of security.
